17 Ethernet Option Board
Precautions for Correct Use Precautions for Correct Use
The differences between the Ethernet Option Board and the CS/CJ series Ethernet Unit are as follows.
• Connect with the CPU Unit by the Host Link (serial communications) whose internal baud rate is 115.2
kbps.
• The size of communications buffers is 8K bytes, one fifty of that of the CS/CJ series Ethernet Unit.
Therefore, the communication performance is slower than the CS/CJ series Ethernet Unit.
Refer to the following processing time (Netwok delay is not included), when accessing to the CP-series CPU
Unit through the Ethernet Option Board.
When accessing to the CP1E CPU Unit and reading 269 words from the DM area, if the cycle time of the
CPU Unit is 10 ms, the processing time will be more than 225 ms and less than 356 ms.
For the CS/CJ series CPU Unit who installs the Ethernet Unit, when executing the same task, the process-
ing time will be approximately 20 ms, up to 17 times faster.

17-1-6 Differences in version of the Ethernet Option Board

CP1W-CIF41 Ethernet Option Board has two versions: version 1 and version 2. Only version 2 can be
used on the CP1E CPU Unit.
Comparison with CP1W-CIF41 Version 1.0
Item
Communications mode
Reset system settings function
Restart function
Max. number of units that can be
mounted
The CP1E CPU Unit does not support the Toolbus protocol, so the Ethernet Option Board version 1.0
cannot be used.
17-8
CP1W-CIF41 version 1.0
Toolbus (CP1L/CP1H)
Not supported
Click the Restart Button from the
Web browser.
Cannot be used
CP1W-CIF41 version 2.0
Toolbus (CP1L/CP1H)
Host Link (CP1E)
Turn ON the Reset Flag A525.01 in
the Auxiliary Area.
• Click the Restart Button from the
Web browser.
• Turn ON the Restart Flag A525.09
in the Auxiliary Area.
1 set
