17-3-3 Default Settings

The default settings of the Ethernet Option Board are shown in the following tables.
Make the initial settings by the Web browser function if the settings are not as follows.
• Common Settings of the FINS/UDP and FINS/TCP Methods
IP Address
Subnet Mask
FINS Node Address
Baud Rate
IP Router Table
• Using the FINS/UDP Method
FINS/UDP Port
Address Conversion Mode
IP Address Table
FINS/UDP Option
Broadcast Option
• Using the FINS/TCP Method
FINS/TCP Port
FINS/TCP Connection Setup
FINS/TCP Protected
The following diagram describes how to restore the initial settings of the Ethernet Option Board.
Auxiliary Area Initializing Flag
(A525.01) is turned ON.
OFF when the initialization is
completed.
Auxiliary Area Restart Flag
(A525.09) is turned ON.
OFF when the Ethernet Option
Board is restarted.
The initialization of the Ethernet
Option Board is completed.
CP1E CPU Unit Software User's Manual(W480)
Item
192.168.250.1
255.255.255.0
1
Auto
None (IP router not enabled)
Item
9,600
Auto (Dynamic)
None
Destination IP address is changed
dynamically
All '1' (4.3 BSD)
Item
9,600
None
Use protection function according to IP
address
Confirm A525.01 is OFF
Confirm A525.09 is OFF
17 Ethernet Option Board
Initial settings
Initial settings
Initial settings
17
17-13
