Typecode and Selection

5.5.1.2 Loop Cable

Description
Hybrid loop cable M23, 90° angled
connector
5 5
Hybrid loop cable M23, straight
connector
Table 5.7 Loop Cable Ordering Numbers

5.5.2 Fieldbus Cables

Description
Fieldbus extension cable, M23
angled to M12 straight
Fieldbus extension cable, M23
straight to M12 straight
Table 5.8 Fieldbus Cable Ordering Numbers
The M8 Ethernet cable for the 3
supplied by Danfoss.

5.5.3 LCP Cable

Description
LCP Cable (SUB-D to M8)
SAB LCP cable
Table 5.9 LCP Cable Ordering Numbers
52
®
VLT Integrated Servo Drive ISD
Length Ordering
[m] number
0.5 175G8900
1 175G8901
2 175G8902
4 175G8903
6 175G8904
8 175G8905
10 175G8906
15 175G8907
20 175G8908
25 175G8909
0.5 175G8910
1 175G8911
2 175G8912
4 175G8913
6 175G8914
8 175G8915
10 175G8916
15 175G8917
20 175G8918
25 175G8919
Length [m] Ordering
number
2 175G8940
2 175G8941
rd
Ethernet port (X3) is not
Length [m] Ordering number
3 175G8942
3 175Z0929
Danfoss A/S © 08/2017 All rights reserved.
®
510 System

5.5.4 LCP Mounting Kit

Description
LCP remote mounting kit (IP21) including LCP,
fasteners, 3 m cable, and gasket.
LCP remote mounting kit (IP21) without LCP, but
including fasteners, 3 m cable, and gasket.
Table 5.10 LCP Mounting Kit Ordering Numbers

5.5.5 Blind Caps

Description
Blind cap for M23 connector, IP67
Blind cap for M23 connector, IP40
Blind cap for M12 connector
Blind cap for M8 connector
Table 5.11 Blind Caps Ordering Numbers

5.5.6 Sensor Cable

Other than the LCP cable (see chapter 5.5.3 LCP Cable), the
cables for the sensor interface (X4) on the advanced
version of the servo drive are not supplied by Danfoss.
Ordering
number
130B1170
130B1117
Ordering number
175G8805
175G8183
175G7162
175G8785
