Introduction

1 Introduction
Programming Guide
Software version: 6.1x
This Programming Guide can be used for all FC 300 frequency
converters with software version 6.1x.
The software version number can be seen from par. 15-43 Software
Version.

1.1.1 Approvals

1.1.2 Symbols

Symbols used in this guide.
NOTE
Indicates something to be noted by the reader.
Indicates a general warning.
Indicates a high-voltage warning.
*
Indicates default setting
FC 300 Programming Guide

1.1.3 Abbreviations

Alternating current
American wire gauge
Ampere/AMP
Automatic Motor Adaptation
Current limit
Degrees Celsius
Direct current
Drive Dependent
Electro Magnetic Compatibility
Electronic Thermal Relay
Frequency Converter
Gram
Hertz
Kilohertz
Local Control Panel
Meter
Millihenry Inductance
Milliampere
Millisecond
Minute
Motion Control Tool
Nanofarad
Newton Meters
Nominal motor current
Nominal motor frequency
Nominal motor power
Nominal motor voltage
Parameter
Protective Extra Low Voltage
Printed Circuit Board
Rated Inverter Output Current
Revolutions Per Minute
Regenerative terminals
Second
Synchronous Motor Speed
Torque limit
Volts
The maximum output current
The rated output current supplied by the
frequency converter
®
