Parameter Descriptions
16-66 Digital Output [bin]
Range:
0 [0 - 15 ]
*
16-67 Pulse Input #29 [Hz]
3 3
Range:
0 N/A [0 - 130000 N/A] View the actual frequency rate on
*
16-68 Freq. Input #33 [Hz]
Range:
0 [0 - 130000 ] View the actual value of the frequency applied
*
16-69 Pulse Output #27 [Hz]
Range:
0 [0 - 40000 ] View the actual value of pulses applied to
*
16-70 Pulse Output #29 [Hz]
Range:
0 [0 - 40000 ] View the actual value of pulses at terminal 29 in
*
16-71 Relay Output [bin]
Range:
0 N/A [0 - 511 N/A]
*
16-72 Counter A
Range:
0 [-2147483648 -
*
2147483647 ]
150
FC 300 Programming Guide
Function:
View the binary value of all digital outputs.
Function:
terminal 29.
Function:
at terminal 33 as an impulse input.
Function:
terminal 27 in digital output mode.
Function:
digital output mode.
This parameter is available for FC 302 only.
Function:
View the settings of all relays.
R eadout choic e (P ar . 16-71):
R ela y output (bin):
0 0 0 0 0 bin
OptionB car d r ela y 09
OptionB car d r ela y 08
OptionB car d r ela y 07
P o w er car d r ela y 02
P o w er car d r ela y 01
Function:
View the present value of Counter A.
Counters are useful as comparator operands,
see par. 13-10 Comparator Operand.
The value can be reset or changed either via
digital inputs (par. group 5-1*) or by using
an SLC action (par. 13-52 SL Controller
Action).
MG.33.M9.02 - VLT
16-73 Counter B
Range: Function:
0 [-2147483648 - View the present value of Counter B.
*
2147483647 ] Counters are useful as comparator operands
(par. 13-10 Comparator Operand).
The value can be reset or changed either via
digital inputs (par. group 5-1*) or by using
an SLC action (par. 13-52 SL Controller
Action).
16-74 Prec. Stop Counter
Range:
0 [0 - 2147483647 ] Returns the actual counter value of precise
*
16-75 Analog In X30/11
Range:
0.000 N/A [-20.000 - 20.000 N/
*
A]
16-76 Analog In X30/12
Range:
0.000 N/A [-20.000 - 20.000 N/
*
A]
16-77 Analog Out X30/8 [mA]
Range:
0.000 N/A [0.000 - 30.000 N/A] View the actual value at input
*
16-78 Analog Out X45/1 [mA]
Range:
0.000 [0.000 - 30.000 ] View the actual value at output X45/1.
*
16-79 Analog Out X45/3 [mA]
Range:
0.000 [0.000 - 30.000 ] View the actual value at output X45/3.
*
®
is a registered Danfoss trademark
Function:
counter (par. 1-84 Precise Stop Counter
Value).
Function:
View the actual value at input
X30/11 of MCB 101.
Function:
View the actual value at input
X30/12 of MCB 101.
Function:
X30/8 in mA.
Function:
The value shown reflects the selection in
par. 6-70 Terminal X45/1 Output.
Function:
The value shown reflects the selection in
par. 6-80 Terminal X45/3 Output.
