13-10 Comparator Operand
Array [6]
Option: Function:
[5] Motor torque Motor torque [5] [Nm]
[6] Motor power Motor power [6] [kW] or [hp]
[7] Motor voltage Motor voltage [7] [V]
[8] DC-link voltage DC-link voltage [8] [V]
[9] Motor thermal Motor thermal [9] Expressed as a percent-
age.
[10] Drive thermal VLT thermal [10] Expressed as a percentage.
[11] Heat sink Heat sink temp [11] Expressed as a percent-
temp. age.
[12] Analog input Analog input AI53 [12] Expressed as a
AI53 percentage.
[13] Analog input Analog input AI54 [13] Expressed as a
AI54 percentage.
[14] Analog input Analog input AIFB10 [14] [V]. AIFB10 is
AIFB10 internal 10 V supply.
[15] Analog input Analog input AIS24V [15] [V] Analog input
AIS24V AICCT [17] [°]. AIS24V is switch mode power
supply: SMPS 24 V.
[17] Analog input Analog input AICCT [17] [°]. AICCT is control
AICCT card temperature.
[18] Pulse input Pulse input FI29 [18] Expressed as a percent-
FI29 age.
[19] Pulse input Pulse input FI33 [19] Expressed as a percent-
FI33 age.
[20] Alarm number Alarm number [20] The error number.
[21] Warning
number
[22] Analog input
x30 11
[23] Analog input
x30 12
[30] Counter A Counter A [30] Number of counts
[31] Counter B Counter B [31] Number of counts
[50] FALSE False [50] Enters the fixed value of false in
the comparator.
[51] TRUE True [51] Enters the fixed value of true in
the comparator.
[52] Control ready Control ready [52] The control board
receives supply voltage
[53] Drive ready Drive ready [53] The frequency converter is
ready for operation and applies a supply
signal on the control board.
[54] Running Running [54] The motor is running.
[55] Reversing Reversing [55] The output is high when the
frequency converter is running counter
FC 300 Programming Guide
13-10 Comparator Operand
Array [6]
Option:
[56]
[60]
[61]
[62]
[65]
[66]
[67]
[68]
[69]
[70]
[71]
[72]
[75]
[76]
[77]
®
MG.33.M9.02 - VLT is a registered Danfoss trademark
Function:
clockwise (the logical product of the status
bits "running" AND "reverse")
In range In range [56] The motor is running within
the programmed current and speed ranges
set in par. 4-50 Warning Current Low to
par. 4-53 Warning Speed High.
On reference On reference [60] The motor is running on
reference.
Below Below reference, low [61] The motor is
reference, low running below the value given in
par. 4-54 Warning Reference Low
Above ref, high Above reference, high [62] The motor is
running above the value given in
par. 4-55 Warning Reference High
Torque limit Torque limit [65] The torque limit, set in
par. 4-16 Torque Limit Motor Mode or
par. 4-17 Torque Limit Generator Mode, has
been exceeded.
Current limit Current limit [66] The motor current limit,
set in par. 4-18 Current Limit, has been
exceeded.
Out of current Out of current range [67] The motor current
range is outside the range set in par. 4-18 Current
Limit.
Below I low Below I low [68] The motor current is lower
than set in par. 4-50 Warning Current Low.
Above I high Above I high [69] The motor current is
higher than set in par. 4-51 Warning Current
High.
Out of speed Out of speed range [70] The speed is outside
range the range set in par. 4-52 Warning Speed
Low and par. 4-53 Warning Speed High.
Below speed Below speed low [71] The output speed is
low lower than the setting in par. 4-52 Warning
Speed Low.
Above speed Above speed high [72] The output speed is
high higher than the setting in par. 4-53 Warning
Speed High.
Out of feedb. Out of feedb. Range [75] The feedback is
range outside the range set in par. 4-56 Warning
Feedback Low and par. 4-57 Warning
Feedback High.
Below feedb. Below feedb. Low [76] The feedback is below
low the limit set in par. par. 4-56 Warning
Feedback Low.
Above feedb. Above feedb. High [77] The feedback is
high above the limit set in par. 4-57 Warning
Feedback High.
