Tags with Black Marks
Perforation
Distance
Feeding Direction
Measurement
Paper Roll, Outer Diameter:
Paper Roll, Core Diameter:
Tag Width:
Distance between perforations:
Paper Thickness:
Black Mark Margin:
Black Mark Width:
Black Mark Length:
Black Mark Position Accuracy:
Black Mark Density:
Perforation (paper/gap):
The end of the paper web should be attached to the core with tape. Roll wound with printable side facing outward.
Intermec ColorCoder V4 – Installation & Operation Ed. 1
Tag Width
Print Side
Allowed Values (mm)
76.2 – 180
76.2
50.8 – 101.6
38.1 – 406.4
0.18 – 0.26
1.0
2 – 4
30.0
2
1.1
1.0/3.0
Only use Collux labels!
Mark Margin
Mark Length
Feeding Direction
Tolerance (mm)
Remarks
N/A
N/A
N/A
N/A
N/A
+0.5/-1.0
Edge of backing paper to edge of mark
0.5
1.0
0.3
Displacement between centre of mark
and leading edge of tag
N/A
MacBeth reflection densitometer
–
Important!
Chapter 8
Specifications
Mark Width
Backside
86
