Tickets with Black Mark

⇐ a ⇒ Media Width
Maximum:
Minimum:
⇐ b ⇒ Copy Length
Minimum:
Maximum:
⇐ c ⇒ LSS Detection Position
Variable, see Chapter 12.
⇐ d ⇒ Black Mark Width
The detectable width of the black mark should be at least 5.0 mm (0.2
inches) on either side of the LSS detection point.
⇐ e ⇒ Black Mark Length
Maximum:
Common:
Minimum:
⇐ f ⇒ Black Mark Y-Position
It is recommended that you place the black mark as close to the front
edge of the ticket as possible and use a negative Stop Adjust value to
control the media feed, so the tickets can be properly torn off.
Media Type Setup
• Ticket (w mark)
Note: Preprint that may interfere with the detection of
the black mark should be avoided. However, the Intermec
Fingerprint statement LBLCOND allows the sensor to be
temporarily disabled during a specified amount of media feed
in order to avoid unintentional detection, see Intermec Finger-
print manuals.
Note: The black mark should be non-reflective carbon black on
a whitish background. Do not allow any perforations to break
the edge of the media as this may cause the media to split and
jam the printer.
Intermec EasyCoder PM4i—User's Guide (Fingerprint version)
Appendix B—Media Specifications
114.3 mm (4.50 inches)
25.0 mm (1.00 inches)
20.0 mm (0.8 inches)
depends on SDRAM size
21.3 mm (0.83 inches)
12.5 mm (0.5 inches)
5.0 mm (0.2 inches)
