9.8
Setting
Margins
Intermec ColorCoder V4 – Installation & Operation Ed. 1
Use the following procedure to set the margins and define the area
to be printed, Note that the actual area that can be printed will in
general be somewhat less than the area defined by the set margins.
For example, setting a top margin of 5 mm will result in printing that
is actually 7 mm from the top edge. To set margins corresponding
to exact printed measurements, enter values as indicated below.
Allowed range is 0 – 30 mm for all margins.
1.4 mm
LABELS
2.0 mm
Caution:
Turning the printer off without first saving the settings will cause
settings to be deleted, see chapter 4.14.
. If "READY" is displayed on the display panel, press the <On
1
line> key.
OFF LINE
. Press the <Menu> key.
2
PAPER TYPE
. Press the <Cursor right> key twice
3
PAPER SET.
. Press the <Enter> key.
4
PRINT PAGES SET.
. Press the <Cursor right> key until this menu appears on the
5
display panel.
MARGIN SET.
. Press the <Enter> key.
6
TOP MARGIN SET.
Chapter 9
Advanced Paper Settings
3.4 mm
2.5 mm
2.5 mm
1.5 mm
TAGS
2.7 mm
3.4 mm
97
