4.13 Stop Position
Alignment
Note:
If an optional automatic cutter is fitted,
this function is replaced by the "Cutter
Pos. Adj" function, see the ColorCoder
901/V4 Cutter Installation Instructions
(Part No. 1-960405-02 or later).
Intermec ColorCoder V4 – Installation & Operation Ed. 1
This adjustment is used to control the amount of paper feed after
printing so as to align the gaps between labels or perforation
between tags with the edge of the manual cutter. Adjustable range
is -3 to +3 mm.
Caution:
Turning the printer off without first saving the settings will cause
settings to be deleted, see chapter 4.14.
. Make sure that the cutting position is at the centre between two
1
labels or tags on the delivered paper.
. If the cutting position is not at the centre between two labels,
2
adjust the stop position.
. Continuing from chapter 4.12, the display panel shows this
3
message.
OFF LINE
. Press the <Menu> key.
4
PAPER TYPE
. Press the <Cursor right> key four (4) times until this menu
5
appears on the display panel.
MAINTENANCE
. Press the <Enter> key.
6
TEST PRINT
. Press the <Cursor right> key twice (2).
7
POSITION ADJ.
. Press the <Enter> key.
8
V-NOZZLE ADJ.
Chapter 4
Installation
35
