4.12 Print Position

Alignment,
cont'd.
T-K = Top-Black
K-C = Black-Cyan
C-M = Cyan-Magenta
M-Y = Magenta-Yellow
Intermec ColorCoder V4 – Installation & Operation Ed. 1
. Continuing from chapter 4.10, the display panel shows:.
1
OFF LINE
. Press the <Menu> key.
2
PAPER TYPE
. Press the <Cursor right> key four (4) times until this menu
3
appears:
MAINTENANCE
. Press the <Enter> key.
4
TEST PRINT
. Press the <Cursor right> key twice (2).
5
POSITION ADJ.
. Press the <Enter> key.
6
V-NOZZLE ADJ.
. Press the <Enter> key again.
7
T-K GAP ADJ.
. Four different gaps can be adjusted:
8
T-K gap: Just press the <Enter> key.
K-C gap: Press <Cursor right> key once, then <Enter>.
C-M gap: Press <Cursor right> key twice, then <Enter>.
M-Y gap: Press <Cursor right> key three time, then <Enter>.
One of the following four menus will be displayed.
T-K GAP
K-C GAP
C-M GAP
M-Y GAP
. Press the <Cursor right> key. A cursor appears in the menu, e.g.
9
M-Y GAP
Chapter 4
= 00
= 0
= 0
= 0
=_0
Installation
33
