Appendix B — Media Specifications

Tickets With Black Mark

150 EasyCoder PX4i Bar Code Label Printer User's Guide (Fingerprint Version)
(a) Media Width
Minimum: 25 mm (1.00 in)
Maximum: 120 mm (4.72 in)
(b) Copy Length
Minimum: 20.0 mm (0.8 in)
Maximum: 8 dots/mm (203.2 dpi): 6,143 mm (241 in)
11.81 dots/mm (300 dpi): 4,162 mm (163 in), provided there is
a sufficient amount of free SDRAM memory
(c) LSS Detection Position: Variable,
page 132.
(d) Black Mark Width
Recommended: 10.0 mm (0.39 in)
Minimum: 5.0 mm (0.20 in)
Maximum: Full media width
(e) Black Mark Length
Recommended: 3.2 mm (0.13 in)
Minimum: 1.27 mm (0.05in)
Maximum: 25.0 mm (0.98 in)
(f ) Black Mark Y-Position
It is recommended that you place the black mark as close to the
front edge of the ticket as possible and use a negative Stop Adjust
value to control the media feed, so the tickets can be properly
torn off. The black mark can be placed either on the top or at the
back of the media.
Black Mark Characteristics
Maximum reflectance: 15%, 940 nm
Difference between mark and media: 55%
Media Type Setup: Mark Stock
Note: Handle perforated media carefully to avoid rips or breaks
along the perforations. Broken or ripped perforations, particularly
at the edges, may cause the media to break or misfeed during
printing.
see"Label Stop Sensor" on
