8.3
Labels with Black Marks
Outer
Margin
Feeding Direction
Measurement
Paper Roll, Outer Diameter:
Paper Roll, Core Diameter:
Paper Width (incl. backing paper):
Label Length:
Paper Thickness:
Backing Paper Margin, Outer Side:
Backing Paper Margin, Inner Side:
Label Gap:
Label Corner Radius:
Black Mark Margin:
Black Mark Width:
Black Mark Length:
Black Mark to Label Edge:
Black Mark Density:
The end of the paper web should be attached to the core with tape. Roll wound with printable side facing outward.
Intermec ColorCoder V4 – Installation & Operation Ed. 1
Paper Width
Inner
Margin
Corner
Radius
Label Gap
Backing Paper
Allowed Values (mm)
76.2 – 180
76.2
50.8 – 101.6
38.1 – 406.4
0.18 – 0.26
2.3
2.0
2 – 9
3.0
1.0
2 – 4
30.0
0
1.1
Only use Collux labels!
Mark Margin
Mark Length
Feeding Direction
Tolerance (mm)
Remarks
N/A
N/A
N/A
N/A
N/A
–
Outer side = Side closest to control panel
0.5
Inner side = Side aligned with printer
0.3
0.3
+0.5/-1.0
Edge of backing paper to edge of mark
0.5
1.0
0.3
MacBeth reflection densitometer
Important!
Chapter 8
Specifications
Mark Width
Backside
84
