10. Advanced Printer Settings
10.1 Interface
Setting
Intermec ColorCoder V4 – Installation & Operation Ed. 1
The advanced printer settings are such settings that you rarely or
never need to change, since the default settings most likely will fit
your application.
Caution:
Turning the printer off without first saving the settings will cause
settings to be deleted, see chapter 4.14.
The ColorCoder V4 is fitted with a standard parallel interface
(Centronics). There are three types, which differ in regard of the
interaction of the BUSY and /ACK signals. By default, the printer
is set for type 1.
Type 1 (default)
BUSY
ACK
1 S
Type 2
BUSY
ACK
Type 3
BUSY
ACK
6 S
. If "READY" is displayed on the display panel, press the <On
1
line> key.
OFF LINE
. Press the <Menu> key.
2
PAPER TYPE
. Press the <Cursor right> key four (4) times.
3
MAINTENANCE
. Press the <Enter> key.
4
TEST PRINT
Chapter 10
4 S
99
