8.4

Tags with Detection Holes

Tag Width
Perforation
Distance
Feeding Direction
Print Side
Measurement
Paper Roll, Outer Diameter:
Paper Roll, Core Diameter:
Tag Width:
Distance between perforations:
Paper Thickness:
Detection Hole Width:
Detection Hole Length:
Detection Hole Corner Radius:
Detection Hole Alignment Margin:
Detection Hole Position Accuracy:
Perforation (paper/gap):
The end of the paper web should be attached to the core with tape. Roll wound with printable side facing outward.
Intermec ColorCoder V4 – Installation & Operation Ed. 1
Hole
Width
Allowed Values (mm) Tolerance (mm)
76.2 – 180
76.2
50.8 – 101.6
38.1 – 406.4
0.18 – 0.26
2 – 9
7.0
2.0
4.3
1.0
1.0/3.0
Important!
Only use Collux labels!
Chapter 8
Hole Alignment
Length Margin
Hole Position
Corner
Radius
Remarks
N/A
N/A
N/A
N/A
N/A
0.2
0.3
–
0.2
0.2 Leading edge of hole to perforation line
–
Specifications
