9.4
Setting Paper
Width and
Length
Note!
Printing will not proceed if loaded paper
size is different from set paper size.
Be sure to set the paper size in accordance
with the size of paper to be printed on.
Intermec ColorCoder V4 – Installation & Operation Ed. 1
Set paper size by entering the height and width of one sheet of label
or tag paper according to the following procedure. Paper height and
width settings must be in millimetres. Refer to chapter 8 for
information on maximum and minimum values.
Labels
LENGTH
WIDTH
Note:
Printing will not proceed if loaded paper size is different from the
set paper size.
. After setting the Top of Form according to chapter 9.3, proceed
1
as follows.
PAPER WIDTH SET.
. Press the <Enter> key.
2
PAPER WIDTH =102
. "102" is the default width value for "Paper Type 1". Press the
3
<Cursor right> key. A cursor appears under the number on the
display panel.
PAPER WIDTH =102
. Use the <Menu> key to increment, and the <Enter> key to
4
decrement the number above the cursor. Use the <Cursor left>
and <Cursor right> to move the cursor between the digits.
PAPER WIDTH =051
. After setting all digits, press the <Cursor right> key while the
5
cursor is below the last digit. The cursor disappears from the
display panel. Press the <Enter> key to set the paper width.
PAPER LENGTH SET
. Press the <Enter> key.
6
PAPER LENGTH=076
Chapter 9
Advanced Paper Settings
Tags
LENGTH
WIDTH
91
