4.8
Paper Roll
Loading,
cont'd.
Intermec ColorCoder V4 – Installation & Operation Ed. 1
. Put back the front roll retainer on the take-up shaft as close to the
4
paper roll as possible. Align the fixing screw with the grooves on
the take up shaft and tighten the fixing screw.
Fixing Screw
Groove
. Untighten the fixing screw on the front paper guide and pull out
5
the guide as far as it goes.
. Pull out the paper, pass it over the paper arm, and thread it
6
between the front and inner paper guides. Rewind the paper to
take up all excessive slack, that could interfere with the roll
cover.
Chapter 4
Fixing Screw
Paper Arm
Installation
23
