EXi: MS-20EX
Program P9: AMS Mixers
The AMS Mixers combine two AMS sources into one, or
process an AMS source to make it into something new.
For instance, they can add two AMS sources together, or use
one AMS source to scale the amount of another. You can
also use them to modify the response of realtime controllers.
The AMS Mixer outputs appear in the list of AMS sources,
just like other controllers.

9-1: AMS Mixers 1-2

9-2: AMS Mixers 3-4

The MS-20EX's AMS Mixers are identical to those of the
AL-1 (although the MS-20EX has four, to the AL-1's two).
For detailed explanations, please see "9–1: AMS Mixer," on
page 227.
326
This also means that the original, unmodified inputs to the
AMS Mixers are still available as well. For instance, if you
use Aftertouch as an input to a AMS Mixer, you can use the
processed version of the Aftertouch to control one AMS
destination, and the original version to control another.
Finally, you can cascade the AMS Mixers together–for
instance, you can use AMS Mixer 1 as an input to AMS
Mixer 2.
