KEB COMBIVERT F5 BASIC Applications Manual page 98

Functional Description
ru.25 Output terminal state
Adr.
0218h
Display of the external and internal digital output set currently. According to following table a specific decimal value is
given out for each digital output. If several outputs are set, the sum of the decimal values is indicated.
Bit -No.
ru.26 Active parameter set
Adr.
021Ah
The frequency inverter F5-GENERALand F5-BASIC can fall back on 8 internal parameter sets (0-7). Through programming
the inverter can change parameter sets autonomously and can thus start different modes of operation. This parameter
shows the parameter set, with which the inverter is operating currently. Independent of it another parameter set can be
edited by bus (also see chapter 6.8 „Parameter sets").
ru.27 Analog input 1 / display before amplification
Adr.
021Bh
This parameter indicates the value of the analog signal AN1 on the differential voltage input (terminal X2A.1 / X2A.2)
before signal amplification in percent. In dependence on An.0 the indicated value 0...±100 % corresponds to: 0...±10 V;
0...±20 mA or 4...20 mA (also see Chapt. 6.2 „Analog inputs").
ru.28 Analog input 1 / display after amplification
Adr.
021Ch
This parameter shows the value of the analog signal AN1 in percent after passing the characteristic amplifier. The range
of indication is limited to ±400 % (also see Chapt. 6.2 „Analog inputs").
Chapter Section Page
6 1 12
min max
0 255
Decimal value
0 1
1 2
2 4
3 8
4 16
5 32
6 64
7 128
min max
0 7
min max
-100 100
min max
-400 400
Date Name: Basis
24.06.02 KEB COMBIVERT F5-G / B
Operating and Appliance Data
-
1
Output
O1 (transistor output 1)
O2 (transistor output 2)
R1 (relay RLA,RLB,RLC)
R2 (relay FLA,FLB,FLC)
OA (internal output A)
OB (internal output B)
OC (internal output C)
OD (internal output D)
1
%
0.1
%
0.1
default
-
Terminal
X2A.18
X2A.19
X2A.24...26
X2A.27...29
none
none
none
none
default
-
-
default
-
default
-
