KEB COMBIVERT F5 BASIC Applications Manual page 101

Operating and Appliance Data
ru.38 Power module temperature
Adr.
0226h
ru.38 shows the current power moduls temperature of the inverter.
ru.39 OL - counter display
Adr.
0227h
In order to preclude „E.OL" - errors by too high load (load reduction in due time), the internal count of the OL-counter can
be made visible with this indication. At 100 % the inverter switches off with error „E.OL". The error can be reset only after
a cooling time (blinking display „E.nOL").
ru.40 Operating hours meter
Adr.
0228h
The operating hours meter shows the time the inverter was switched on. The indicated value comprises all operating
phases. On reaching the maximum value (approx. 7.5 years) the indication remains on the maximum value.
ru.41 Modulation hours meter
Adr.
0229h
The modulation hours meter shows the time the inverter was active (power modules controlled). On reaching the maximum
value (approx. 7.5 years) the indication remains on the maximum value.
ru.42 Modulation factor
Adr.
022Ah
The modulation factor shows the output voltage in percent. 100 % correspond to the input voltage (no-load). At a value
of > 100 % the inverter works with overmodulation.
ru.43 Timer 1 / display
Adr.
022Bh
The count of the free-programmable timer 1 is indicated. The display is done either in seconds, in hours or in slopes/100
(see LE.21). The counter can a adjusted to any chosen value by keyboard or bus. The programming of the counter is
done with the parameters LE.17...LE.21 (also see Chapt. 6.9.4 „Timer").
© KEB Antriebstechnik, 2002
All rights reserved
min max
0 150
min max
0 100
min max
0 65535
min max
0 65535
min max
0 110
min max
0 655.35
Name: Basis
KEB COMBIVERT F5-G / B
Functional Description
°C
1
%
1
h
1
h
1
%
1
s / h
0.01
Date
24.06.02
default
-
default
-
default
-
default
-
default
-
default
-
Chapter Section Page
6 1 15
6
