Functional Description
6.3.9
Input Status
(ru.22)
6.3.10 Reset/Input
Selection and
Edge Evaluation
(di.9 / di.10)
6.3.11 Assignment of
the Inputs
Chapter
Section
Page
6
3
8
The internal input status shows the logic condition of the digital inputs which are
internally set for processing. It is unimportant, whether the external terminals are
active or not. If an input is set, the appropriate decimal value according to the table
under 6.3.8 is output. If several inputs are set, then the sum of the decimal values is
output.
With di.9 the reset input is defined according to the table under 6.3.8. If the reset input
shall react to an edge, one or several of the reset inputs defined with di.9 can be
switched to edge evaluation with di.10.
There are two different procedures for the assignment of inputs. Both variants are
locked against each other to give the user maximum flexibility.
List of parameters, that can be assigned with inputs:
Parameter Name
oP.19
Fixed value / input selection 1
oP.20
Fixed value / input selection 2
oP.56
Motorpoti increase / input selection
oP.57
Motorpoti decrease / input selection
oP.58
Motorpoti Reset / input selection
1)
oP.60
Rotation forward (Run) / input selection
oP.61
1)
Rotation reverse (Stop) / input selection
di. 9
Reset / input selection
di.10
2)
Edge evaluation for Reset / input selection
Pn. 4
External fault / input selection
Pn.23
Ramp stop / input selection
Pn.29
DC-braking / input selection
uF. 8
Energy-saving function / input selection
Fr. 7
Parameter set / input selection
Fr.11
Reset set / input selection
An. 3
AN1 save trigger / input selection
An.13
AN2 save trigger / input selection
An.23
AN3 save trigger / input selection
LE.17
Timer 1 Start / input selection
LE.19
Timer 1 Reset / input selection
LE.22
Timer 2 Start / input selection
LE.24
Timer 2 Reset / input selection
cn.11
PID reset / input selection
cn.12
I reset / input selection
cn.13
Fade in reset / input selection
1)
By selecting the source of rotation (oP.1) the adjustment can be changed from
forward/reverse to Run/Stop.
2)
see chapter 6.3.10
Date
Name: Basis
16.04.02
KEB COMBIVERT F5
Digital In- and Outputs
Preadjustment
16 (I1)
32 (I2)
0
0
0
4 (F)
8 (R)
3 (ST+RST)
3 (ST+RST)
64 (I3)
0
128 (I4) 0 at F5-M
0
0
0
0
0
0
0
0
0
0
0
0
0
©
