KEB COMBIVERT F5 BASIC Applications Manual page 141

Digital In- and Outputs
Level 0...7
LE.0...LE.7
Hysteresis 0...7
LE. 8...LE.15
Frequency hysteresis LE.16
Response to warning signals
Pn.8, Pn.10, Pn.12, Pn.14,
© KEB Antriebstechnik, 2002
All rights reserved
These parameters defines the level of the switching conditions. Level 0 (LE.0) applies
for switching condition 0; LE.1 for switching condition 1 ... and so forth.
Setting range:
Step:
Default:
Bei der Vorgabe in Inkrementen entspricht ein Inkrement gleich 0,01.
The hysteresis, in reference to the adjusted values, defines the parameters
LE. 8...LE.15. Hysteresis 0 (LE.8) applies for comparison level 0; LE.9 for comparison
level 1 ... and so forth.
Default:
Frequency:
Voltage:
Analog values:
Current:
Temperature:
LE.16 defines the hysteresis for the status constant-run and tripping frequencies for
the DC-brake.
These parameters determine the behaviour of the inverter in case of warning signals.
To learn more about the adjustment possibilities as well as the performance of the
Pn.16
appropriate drive please refer to Chapter 6.7 „Protective functions".
Name: Basis
KEB COMBIVERT F5
Functional Description
-30000,00...30000,00
0,01
see parameter table
0,5 Hz
1 V
0,5 %
0,5 A
1 °C
