CP - Parameter
Reaction of
external overtemperature
© KEB Antriebstechnik, 2001
All Rights reserved
This parameter determines the response of the drive on the external temperature
monitoring (factory setting = off). In order to activate this function the power circuit
terminals T1/T2 must be connected in accordance with the instruction manual Part 2.
After that the response can be adusted according to following table.
If overheat no longer exists, the message E.ndOH (or A.ndOH) is output. Only then
the error can be reset or the automatic restart can be carried out.
CP.28 Display Reaction
0 E.dOH Immediate disabling of modulation
1 * A.dOH Quick stopping / disabling of
modulation after reaching speed 0
2 * A.dOH Quick stopping/holding toruqe at speed 0
3 A.dOH Immediate disabling of modulation
4 * A.dOH Quick stopping / disabling of
modulation after reaching speed 0
5 * A.dOH Quick stopping/holding toruqe at speed 0
6 * no No effect on the drive;
With CP.31/32 = 9 an external module
can be controlled (e.g. fan)
7 no No effect on the drive;
!Störung existiert nicht! External
Temperature monitoring is not activated
*) If the motor is still too hot after 10 seconds, the error E.dOH is triggered and the
modulation is switched off!
Adjustment range:
Resolution:
Setting range:
Name: Basis
KEB COMBIVERT F5-G / B
Operation
Restart
Remove fault;
Actuate reset
Automatic reset,
if the fault is no
longer
present
- inapplicable -
0...7
1
7
