Special Functions
6.9.3 Motor Potentiome-
ter Function
Fig. 6.9.3 Motor potentiometer function
oP.56 Input selection
Increase motor poti value
oP.57 Input selection
Decrease motor poti value
oP.58 Input selection
Reset on oP.55
oP.52 Motor poti / Value
Presetting via parameter
±100%
(oP.59 is being ignored)
Bit Value Input
0 1 ST (Prog. input „Control release/Reset")
1 2 RST (Prog. input „Reset")
2 4 F (Prog. input „forward")
3 8 R (Prog. input „reverse")
4 16 I1 (Prog. input 1)
5 32 I2 (Prog. input 2)
6 64 I3 (Prog. input 3)
7 128 I4 (Prog. input 4)
8 256 IA (Internal input A)
9 512 IB (Internal input B)
10 1024 IC (Internal input C)
11 2048 ID (Internal input D)
© KEB Antriebstechnik, 2002
All rights reserved
This function simulates a mechanic motor potentiometer. Over two inputs the motor
potentiometer value can be increased or decreased.
oP.50 Motor potentiometer / Function
Bit0 Bit1
x 0
x 1
0 x
1 x
100%
oP.54
oP.55
oP.59
0%
oP.59
oP.53
-100%
ru.37 Display motor poti value
-100...0...100 %
Rotation direct.
+ = forward
- = reverse
to oP.1 value „6 u. 7"
Terminal
X2A.16
X2A.17
X2A.14
X2A.15
X2A.10
X2A.11
X2A.12
X2A.13
none
none
none
none
Name: Basis
KEB COMBIVERT F5
Functional Description
Meaning
Set-programmable
Not set-programmable
No motor poti reset after Power-on
Reset on oP.55 after Power-on
oP.59
oP.59
Setpoint
An54 Target analog
Parameter settings
to oP.0
value „4"
Parameter setting by the
motorpoti / aux function
Date
18.04.02
t
1 0
Aux
An.53
