The parameter groups „ru" , „Sy" and „In" are described in this chapter. They serve
for the operational monitoring, error analysis and evaluation as well as for the unit
identification.
The ru- (run) parameter group represents the multimeter of the inverter. Here speeds,
currents, voltages etc. are displayed, with those a statement about the operating
condition of the inverter can be made. Especially during startup or trouble shooting
on a plant, this can turn out to be a great aid. Following parameters are available:
ru. 0 Inverter status
ru. 1 Set value display
ru. 2 Ramp output display
ru. 3 Actual frequency display
ru. 4 Encoder 1 frequency
ru. 5 Encoder 2 frequency
ru. 6 Calculated actual frequency
ru. 7 Actual value display
ru. 9 Encoder 1 speed
ru. 10 Encoder 2 speed
ru. 13 Actual utilization
ru. 14 Peak utilization
ru. 15 Apparent current
ru. 16 Apparent current/peak value
ru. 17 Active current
ru. 18 DC-link voltage
ru. 19 DC-link voltage/peak value
ru. 20 Output voltage
ru. 21 Input terminal state
ru. 22 Internal input state
ru. 23 Output condition state
ru. 24 State of output flags
ru. 25 Output terminal state
ru. 26 Active parameter set
ru. 27 AN1 display before amplification
ru. 28 AN1 display after amplification
ru. 29 AN2 display before amplification
ru. 30 AN2 display after amplification
ru. 31 AN3 display before amplification
ru. 32 AN3 display before amplification
ru. 33 Analog output 1 display before amplification
ru. 34 Analog output 1 display after amplification
ru. 35 Analog output 2 display before amplification
ru. 36 Analog output 2 display after amplificaiton
ru. 37 Motorpoti - actual value
ru. 38 Power module temperature
ru. 39 OL-counter display
ru. 40 power on counter
ru. 41 Modulation on counter
ru. 42 Modulation grade
ru. 43 Timer 1 display
ru. 44 Timer 2 display
ru. 45 Actual carrier frequency
ru. 46 Motor temperature
ru. 52 External PID out display
ru. 53 AUX display
ru. 68 Rated DC voltage
