KEB COMBIVERT F5 BASIC Applications Manual page 266

Functional Description
6.11.3 Used Parameters
Parameter
uF 7 Energy saving factor
uF16 Autoboost configuration
uF17 Autoboost gain
cS 0 Speed control configuration
cS 1 Actual source
cS 4 Speed control frequncy limit
cS 6 KP-speed
cS.9 KI-speed
Chapter Section Page
6 11 6
Addr.
0507 X X –
0510 X X –
0511 X X –
0F00 X X –
0F01 X X –
0F04 X X –
0F06 X X –
0F09 X X –
Date Name: Basis
05.02.02 KEB COMBIVERT F5-G / B
min max
0,0 130,0 0,1
0 3 1
0,00 2,50 0,01
0 63 1
0 2 1
0 200 0,0125
0 32767 1
0 32767 1
Regulated Operation
[?] Notes
default
70,0 % –
0 – –
1,25 – –
0 – –
2 – not at B housing
25 Hz dep. on ud.2
50 – –
500 – –
