Operating and Appliance Data
ru. 4 Encoder 1 frequency
Adr.
0204h
The displayed value corresponds to the actual frequency measured at the encoder input 1. The value „0" is indicated,
even if no encoder interface is available.
ru. 5 Encoder 2 frequency
Adr.
0205h
The displayed value corresponds to the actual frequency measured at the encoder input 2. The value „0" is indicated,
even if no encoder interface is available.
ru. 6 Calculated actual frequency
Adr.
0206h
The displayed value corresponds to the actual frequency calculated from the inverter.
ru. 7 Actual value display
Adr.
0207h
The displayed value corresponds to the rotary field frequency given out at the inverter output (cS.0 Bit 0...2 = 0 or 1). At
cS.0 Bit 0...2 = 2 the frequency of the channel selected in cS.1 is displayed (ru.4/5/6).
ru. 9 Encoder 1 speed
Adr.
0209h
The displayed speed corresponds to the actual speed measured at the encoder input 1. The value „0" is indicated, even
if no encoder interface is available.
ru.10 Encoder 2 speed
Adr.
020Ah
The displayed speed corresponds to the actual speed measured at the encoder input 2. The value „0" is indicated, even
if no encoder interface is available.
©
KEB Antriebstechnik, 2002
All rights reserved
!ud.2!
min
max
-400
400
!ud.2!
min
max
-400
400
!ud.2!
min
max
-400
400
!ud.2!
min
max
-400
400
!ud.2!
min
max
-4000
4000
!ud.2!
min
max
-4000
4000
Name: Basis
KEB COMBIVERT F5-G / B
Functional Description
!ud.2!
0,0125
Hz
!ud.2!
0,0125
Hz
!ud.2!
0,0125
Hz
!ud.2!
0,0125
Hz
!ud.2!
0,125
rpm
!ud.2!
0,125
rpm
Date
24.06.02
default
-
default
-
default
-
default
-
default
-
default
-
Chapter
Section
Page
6
1
7
6
