Special Functions
Timer Reset condition
(LE.20/25)
Comparison level 0...7
(LE.0...LE.7)
Used Parameters
R/W PROG.
Param. Adr.
ru.43 022Bh
ru.44 022Ch
LE.0 0D00h
LE.1 0D01h
LE.2 0D02h
LE.3 0D03h
LE.4 0D04h
LE.5 0D05h
LE.6 0D06h
LE.7 0D07h
LE.17 0D11h
LE.18 0D12h
LE.19 0D13h
LE.20 0D14h
LE.21 0D15h
LE.22 0D16h
LE.23 0D17h
LE.24 0D18h
LE.25 0D19h
LE.26 0D1Ah
© KEB Antriebstechnik, 2002
All rights reserved
According to following table the conditions can be defined under which the timer is
reset in addition to the inputs. The individual conditions are OR-operated.
Bit -No. Decimal value
0
1
2
3
4
LE.0...LE.7 define the level for the switching conditions 37/38 („timer > level"). If the
timer exceeds the adjusted value the switching condition is set. A level in the range of
-10.737.418,24 bis 10.737.418,23 can be adjusted. But only values of 0...655,34 are
sensible for the counter.
ENTER
min
- - 0,00 655,35
- - 0,00 655,35
- -10737418,24 10737418,23
- -10737418,24 10737418,23
- -10737418,24 10737418,23
- -10737418,24 10737418,23
- -10737418,24 10737418,23
- -10737418,24 10737418,23
- -10737418,24 10737418,23
- -10737418,24 10737418,23
- 0 4095
- 0
- 0 4095
- 0 31
- - 0 31
- 0 4095
- 0
- 0 4095
- 0 31
- - 0 31
Name: Basis
KEB COMBIVERT F5
Functional Description
Condition
1 Modulation on
2 Modulation off
4 Setpoint frequency = Actual frequency
8 Change of parameter set
16 Power-On-Reset
Step
max
default
0,01 0,00
0,01 0,00
0,01 0
0,01 0
0,01 0
0,01 0
0,01 0
0,01 0
0,01 0
0,01 0
1 0
7 1 0
1 0
1 16
1 0
1 0
7 1 0
1 0
1 16
1 0
-
-
-
-
-
-
-
-
-
-
bitcoded
-
bitcoded
-
-
bitcoded
-
bitcoded
-
-
