KEB COMBIVERT F5 BASIC Applications Manual page 90

Functional Description
6.1.2 Overview of the
In-Parameters
6.1.3 Overview of the
Sy-Parameters
Chapter Section Page
6 1 4
The In- (Information) parameter group contains data and information on the identification
of the hardware and software as well as on the type and number of the errors that
occurred. Following parameters are available:
In. 0 Inverter type
In. 1 Rated inverter current
In. 3 Max. switching frequency
In. 4 Rated switching frequency
In. 5 Interface type
In. 6 Software version
In. 7 Software date
In. 8 Software version power circuit
In. 9 Software date power circuit
In. 10 Serial number (date)
In. 11 Serial number (counter)
In. 12 Serial number (Ackn.-No. High)
In. 13 Serial number (Ackn.-No. Low)
In. 14 Customer number (High)
In. 15 Customer number (Low)
In. 16 QS-Number
In. 17 Temperature mode
In. 22 User parameter 1
In. 23 User parameter 2
In. 24 Last error
In. 25 Error diagnosis
In. 26 Error counter OC
In. 27 Error counter OL
In. 28 Error counter OP
In. 29 Error counter OH
In. 30 Error counter OHI
As the name already says the Sy- (system) parameter group contains system-specific
parameters. Following parameters are available:
Sy. 2 Inverter identifier
Sy. 3 Power unit code
Sy. 6 Inverter address
Sy. 7 Baud rate ext. bus
Sy. 9 HSP5 Watchdog time
Sy. 11 Baud rate int. bus
Sy. 32 Scope timer
Sy. 41 Control word high
Sy. 42 Status word high
Sy. 43 Control word long
Sy. 44 Status word long
Sy. 50 Control word low
Sy. 51 Status word low
Sy. 52 Set speed value
Sy. 53 Actual speed value
Sy. 56 Start display address
