Voltage Input / External Power; Supply; Digital Outputs; Relay Outputs - KEB COMBIVERT F5 BASIC Applications Manual

Control Cards
3.1.6 Voltage Input /
External Power

Supply

3.1.7

Digital Outputs

3.1.8

Relay Outputs

© KEB Antriebstechnik, 2001
All Rights reserved
The supply of the control circuit through an external voltage source keeps the control
in operational condition even if the power stage is switched off. To prevent undefined
conditions at external power supply the basic procedure is to first switch on the power
supply and after that the inverter.
Control card GENERAL:
X2A
10 11
Control card GENERAL:
X2A
In case of inductive load on the relay outputs a protective wiring must be provided
(e.g. free-wheeling diode)!
Control card BASIC:
Control card GENERAL:
Name: Basis
KEB COMBIVERT F5-G / B
Hardware
17 18 19 20 21 22 23
+
20...30 V ±0% / 1 A DC
smoothed
10 18 19 20 21 22 23
X2A
24 25 26 27 28 29
max.30VDC/1A
X2A
24 25 26 27 28 29
max. 30 VDC / 1 A
Date
04.12.01
PE
PE
A total of max.
50 mA DC for
both outputs
PE
+
-
PE
Chapter Section Page
3 1 7
3
