Operating and Appliance Data
6.1.6 Description of the In-Parameters
In. 0 Inverter type
Adr.
0E00h
The inverter type is displayed in hexadecimal numbers. The bits have following meaning:
Bit 0-4 Unit size
Bit 5 Voltage class
Bit 6 Phase number
Bit 7 free
Bit 8-12 Housing
Bit 13-15 Control
Example:
In. 1 Rated inverter current
Adr.
0E01h
Display of the rated inverter current in A. The value is determined from the power circuit identification (P-ID) and cannot
be changed.
© KEB Antriebstechnik, 2002
All rights reserved
min max
0h FFFFh
05, 07, 09 etc.
0 = 230 V
1 = 400 V
0 = 1-phase
1 = 3-phase
0 = A
1 = B
2 = C
3 = D
4 = E
5 = F
6 = G
7 = H
8 = I
9 = J
0 = G
1 = M
2 = B
3 = S
4 = A
hex 0
binary 0 0 0 0 0 1 0 0 0 0 0 0 1 0 1 0
decimal 0
=> 10.F5 G-Control / E-housing / 230V / 1ph.
