Analog In- and Outputs
6.2.9 Selection Set
Point-/Auxiliary
Input (An.30)
© KEB Antriebstechnik, 2002
All rights reserved
Following functions are combined in An.30:
- Bit 0..2 Selection of the analog input (AN1, AN2, AN3) as REF analog
- Bit 3..5 Mode of the AUX-Function
- Bit 6..10 Selection source 1 for the AUX-Function
- Bit 11..15 Selection source 2 for the AUX-Function
For possible expansions not all values are defined in the bit groups. Not defined values
have the same function as value 0. The sum of the respective values is to be entered.
Assignment of the analog inputs:
Bit 0..2 Function
Value REF analog
0 AN1 (ru.28) (default)
1 AN2 (ru.30)
2 AN3 (ru.32)
Bit 3..5 Function
Value Mode of the AUX-Function
0 Source 1 (default)
8 Source 1 + Source 2
16 Source 1 * (100% + Source 2)
24 Source1 * Source 2
Bit 6..10 Function
Value Aux-input source 1
0 AN1 (ru.28)
64 AN2 (ru.30) (default)
128 Percental setpoint value (op.5)
192 Motorpoti (ru.37)
256 Process controller output (ru.52)
320 AN3 (ru.32)
Bit 11..15 Function
Value Aux-input source 2
0 AN1 (ru.28)
2048 AN2 (ru.30) (default)
4096 Percental setpoint value (op.5)
6144 Motorpoti (ru.37)
8192 Process controller output (ru.52)
11240 AN3 (ru.32)
x: not for control card BASIC
