Regulated Operation
Configuration speed
controller (cS.0)
Actual value source (cS.1)
- not at B-Control -
Frequency limit
Speed controller (cS.4)
KP-Drehzahl (cS.6)
KI-Drehzahl (cS.9)
© KEB Antriebstechnik, 2002
All rights reserved
Bit Value Description
0,1 0 Speed controller off
1 Process control via technologie controller
2 Slip compensation
3 reserved
2 0 No function
3 0 Change of direction of rotation via the controller not possible
8 Change of direction of rotation via the controller possible
4 0 No controller intervention at f_setting = 0Hz
16 Controller intervention at f_setting = 0Hz
5 0 No slip limiting
32 Slip is limited to max. rated slip x dr.9
The parameter cS.1 determines the actual value source for the speed controller.
Following selections are available:
Value Actual value source
0 Actual value from encoder interface channel 1
1 Actual value from encoder interface channel 2
2 Actual value is calculated internally
The frequency limit defines the maximum controller intervention within the range of
0...200 Hz (dep. on ud.2).
KP-speed defines the proportional component of the speed controller within the range
of 0...32767.
KI-speed defines the integral component of the speed controller within the range of
0...32767.
