Terminal Strip X2A - KEB COMBIVERT F5 BASIC Applications Manual

Hardware
3.1.2

Terminal strip X2A

GENERAL
PIN Function
1 + Set Value input 1
2 - Set Value input 1
3 + Set Value input 2
4 - Set Value input 2
5 Analog Output 1
6 Analog Output 2
7 +10 V Output
8 Analog Mass
9 Analog Mass
10 Progr. Input 1
11 Progr. Input 2
12 Progr. Input 3
13 Progr. Input 4
14 Progr. Input Forward
15 Progr. Input Reverse
16 Progr. Input Control Rel.
17 Progr. Input Reset
18 Transistor Output 1
19 Transistor Output 2
20 +24 V Output
21 20...30 V Input
22 Digital Mass
23 Digital Mass
24 Relay 1 /NO contact
25 Relay 1 /NC contact
26 Relay 1 /switching contact RLC
27 Relay 2 /NO contact
28 Relay 2 /NC contact
29 Relay 2 /switching contact FLC
Chapter Section Page
3 1 4
1 2 3 4 5 6 7 8 9
Name Description
AN1+ The input signal (0...±10 V; 0...±20 mA and 4...20 mA) is determined
AN1- with An.0/10. Specification and control see chap. 6.2.2.
AN2+ Resolution: 12 Bit (BASIC and GENERAL B-housing: 11 Bit)
AN2- Scan time: 1 ms (BASIC: 2 ms)
at directly setpoint input: 250 µs (see chapter 6.4.2)
ANOUT1 The variable for outputting at analog output 2 is determined with
An.31 / 36. Specification and control see chap. 6.2.11.
ANOUT2 Voltage range: 0...±10V, Ri = 100 Ω, Resolution: ±10 Bit
CRF Reference voltage output +10 VDC +5% / max. 4 mA for set value
potentiometer.
COM Mass for analog in- and outputs
COM Mass for analog in- and outputs
I1 Specifications, control and programming of the digital
I2 inputs see chap. 6.3.1...6.3.11
I3 All digital inputs are free programmable.
I4 The control release is firmly linked with the input ST, but can be
F additional occupied with other functions.
R Ri = 2,1 kΩ
ST Scan time: 1 ms (BASIC: 2 ms)
RST
O1 Specifications, control and programming of the digital
O2 transistor outputs see chap. 6.3.12...6.3.22,
a total of max. 50 mADC for both outputs
U approx. 24V DC output (max.100 mA)
out
U Ext. supply voltage for digital in-/outputs, potential 0V (X2A.22/23)
in
0V Potential for digital in-/outputs
0V Potential for digital in-/outputs
RLA Programmable relay output 1 (Terminal X2A.24...26);
RLB Programmable relay output 2 ( Terminal X2A.27...29)
Specifications, control and programming of the relay outputs
FLA see chapter 6.3.11...6.3.17
FLB max. 30 V DC, 1 A
Date Name: Basis
04.12.01 KEB COMBIVERT F5-G / B
1 5 7 8 10 11 14 15 16 20 22
BASIC
10 11 12 13 14 15 16 17 18 19 20 21 22 23
©
Control Cards
24 25 26 27 28 29
24 25 26 27 28 29
