Functional Description
ru.13 Actual utilization
Adr.
020Dh
Display of the current utilization referred to the rated current of the inverter. Only positive values are indicated, thus it is
not possible to differentiate between a motoric or generatoric operation.
ru.14 Peak utilization
Adr.
020Eh
ru.14 permits the detection of short-time peak loads within an operating cycle. The highest occurred value of ru.13 is
stored in ru.14. The peak value memory can be cleared by pressing the keys UP, DOWN or ENTER and by bus through
writing any chosen value to the address of ru.14. Switching off the inverter also results in a clearing of the memory.
ru.15 Apparent current
Adr.
020Fh
Display of the current apparent current. The maximum values depend on the size of the inverter.
ru.16 Apparent current / peak value
Adr.
0210h
ru.16 permits the detection of short-time peak currents within an operating cycle. The highest occurred value of ru.15 is
stored in ru.16. The peak value memory can be cleared by pressing the keys UP, DOWN or ENTER and by bus through
writing any chosen value to the address of ru.16. Switching off the inverter also results in a clearing of the memory.
Chapter Section Page
6 1 8
min max
0 255
min max
0 255
min max
0 unit-dependent
min max
0 unit-dependent
Date Name: Basis
24.06.02 KEB COMBIVERT F5-G / B
Operating and Appliance Data
%
1
%
1
A
0.1
A
0.1
