KEB COMBIVERT F5 BASIC Applications Manual page 85

Parameter
uf 10 max. voltage mode
uf 11 carrier frequency
uf 12 base block time
uf 13 base block voltage level
uf 15 hardw. curr. lim. mode
uf 15 hardw. curr. lim. mode
uf 16 autoboost configuation
uf 17 autoboost gain
uf 18 deadtime comp. mode
uf 19 volt.stab.PT1-timeconst.
© KEB Antriebstechnik, 2002
All Rights reserved
Adr. Control Properties
05 0A B g - - - - - P - - 0
05 0B B g G M S A - P E - 0
05 0C B g G M S A R - - - LTK
05 0D B g G M S A R - - - LTK
05 0F - - G M S A - - - - 0
05 0F B g - - - - - - - - 0
05 10 B g G - - A - P - - 0
05 11 B g G - - A - P - - 0,00
05 12 B g G M - - - - - - 0
05 13 - - G - - A - - - - 0
Name: Basis
KEB COMBIVERT F5-G / B
min. max. Step
2 1
LTK 1
LTK 0,01
LTK 1
2 1
1 1
3 1
2,50 0,01
1 1
10 1
Parameter
default [?] see on Page
0 - 6.5.6
LTK - 6.5.6
LTK s 6.7.9
LTK % 6.7.9
1 - 6.7.3
1 - 6.7.3
0 -
1,20 -
1 - 6.7.9
0 - 6.5.5
Date Chapter Section
5 1
14.06.02
5
Page
13
