Functional Description
PID-Reset condition (cn.10)
Reset by way of digital inputs
(cn.11...13)
PID Output frequeny at 100%
(cn.14)
(only F5-G/B)
Chapter Section Page
6 12 4
With cn.10 it is possible to set the reset conditions for the PID-Controller. Thus simple
speed regulations can be realized for both directions of rotation.
cn.10 Function
0
1
2
For speed regulations adjust the value „2", with that the I-component of the controller
is reset at LS or nOP. The value „1" serves mainly for the start-up, to reset the controller
manually.
The whole controller, the I-component as well as the controller fade-in can be reset via
a digital input. When resetting the masking the fade-in time is valid. For that purpose
the decimal value of the corresponding inputs according to the table below has to be
entered.
cn.11 PID reset / input selection
cn.12 I reset / input selection
cn.13 Fade in reset / input selection
Bit -No. Decimal value Input
0
1
2
3
4
5
6
7
8
9
10 1024
11 2048
This block converts the percental controller output value into a frequency. The
adjustment of cn.14 determines which frequency is output at 100 % controller output
value. A frequency from 0.0...400.0 Hz (dep. on ud.2) can be adjusted. At cS.0 bit
0...1 = 1 the output value added with the ramp output frequency (ru.2) forms the
output frequency (ru.3).
Date Name: Basis
11.02.02 KEB COMBIVERT F5
PID-Controller is not reset
PID-Controller = 0 (is continously reset)
PID-Controller is reset in case of modulation off
1 ST (prog. input „control release / reset")
2 RST (prog. input „reset")
4 F (prog. input „forward")
8 R (prog. input „reverse")
16 I1 (prog. input 1)
32 I2 (prog. input 2)
64 I3 (prog. input 3)
128 I4 (prog. input 4)
256 IA (internal input A)
512 IB (internal input B)
IC (internal input C)
ID (internal input D)
Technology Control
Terminal
X2A.16
X2A.17
X2A.14
X2A.15
X2A.10
X2A.11
X2A.12
X2A.13
none
none
none
none
