KEB COMBIVERT F5 BASIC Applications Manual page 97

Operating and Appliance Data
ru.23 Output condition state
Adr.
0217h
With parameters do.0...do.7 switching conditions can be selected, that serve as a base for setting the outputs. This
parameter indicates which of the selected switching conditions are met before they are linked or inverted by programmable
logic (also see Chapt. 6.3 „Digital outputs"). According to following table a specific decimal value is given out for the
switching conditions. If several of the selected switching conditions are met, the sum of the decimal values is indicated.
Bit -No.
ru.24 State of output flags
Adr.
0217h
Display of the links after logic step 1. The selected switching conditions are linked in logic step 1 (do.8...24) and
indicated here (see Chapt. 6.3 „Digital outputs"). According to following table a specific decimal value is given out for
each linkage. If several links are set, the sum of the decimal values is indicated.
Bit -No.
© KEB Antriebstechnik, 2002
All rights reserved
min max
0 255
Decimal value
0 1
1 2
2 4
3 8
4 16
5 32
6 64
7 128
min max
0 255
Decimal value
0 1
1 2
2 4
3 8
4 16
5 32
6 64
7 128
