Segway Ninebot S Kids - Self-Balancing Scooter Manual

Introduction

S Kids is specially designed for children over 8 years of age (children must learn and ride under the supervision of an adult).
It is lightweight, flexible, and moves freely when you change your center of gravity. The built in voice prompts help you to ride safely. Make sure to follow the instructions. S Kids can also be connected to your mobile phone via Bluetooth to play music.

To reduce the risk of injury, adult supervision is required. Please read the user manual carefully and understand the assembly and usage before allowing child to ride it. Never use in roadways, near motor vehicles, on or near steep inclines or steps, swimming pools or other bodies of water: always wear shoes, and never allow more than 1 rider.

Always step on/off from the back of the S Kids.
Otherwise you risk falls and/or collisions because the steering direction is reversed.

Packing List

When unpacking your S Kids, please verify that the above items are included in the package. If you are missing any components, please contact your dealer/distributor or nearest service center (see Contacts). After verifying that al components are present and in good condition, you can assemble your new S Kids.
Please retain the box and packaging materials in case you need to ship your S Kids in the future.
Always power off your S Kids and unplug the charging cable before assembling, mounting accessories, or cleaning.

Diagram

	Power Button	Press to power on/off the S Kids. The S Kids will beep and automatically power OFF when idle for 10 minutes, or when laid down (horizontal) for over 2 minutes.
	Battery Level [1]	Indicates the remaining battery level. Each dot represents approximately 25% of the battery's power. When the battery is nearly empty, the last dot blinks
	Bluetooth Icon	Flashing blue: Bluetooth is waiting to be connected. Solid blue: the vehicle is connected to a mobile device.

[1] The S Kids will gradually reduce the max speed limit as the battery level gradually decreases. Use the Segway Ninebot app to view the remaining battery and estimated remaining range. When the last dot blinks, you wi hear a voice prompt or a continuous beep, at this time, please get off immediate y to prevent injury.

Assembling Your Device

1. Slide the steering bar onto the mounting bracket.

2. Install the two screws. Tighten securely with the included hex wrench.

3. Peel off the back glue. Press the rubber cap onto the steering bar until it snaps in place.


Charging

Open the rubber cap

Insert the plug into the socket

• The charger is not a toy. Children should not be allowed to touch the charging device
• Do not connect the charger if the charge port or charge cable is wet. The battery pack is only to be charged by adults
• Your S Kids is fully charged when the LED on the charger changes from red (charging) to green (trickle charge). Close the rubber cap when not charging

Active your Device

There are safety risks when learning to ride the S Kids. You must read the Riding Safety and follow the New Rider Tutorial in the app before your first ride.
For your safety, your S Kids is not activated at this time and wil beep occasionally or have a voice reminder after powered on.
Until activated, the S Kids maintains a very low riding speed and steering sensitivity, and should not be ridden. Install the app on your mobile device (with Bluetooth 4.1 or above), connect to the S Kids with Bluetooth, follow the app instructions to activate your S Kids and follow the training procedures. Scan the QR code on the left to download the app.

Segway Ninebot App

1. Install the app and register or log in.

2. Power ON the S Kids The Bluetooth icon blinking indicates the S Kids is waiting for a connection.

3. Click Vehicle > Search device to connect Your S Kids will beep once or have a voice prompt when the Bluetooth connection is successful.

4. FoIow the prompts to watch the Riding Safety video, complete the New Rider Tutorial, and then activate the S Kids.


Learning to Ride

Wear an approved helmet and other protective gear to minimize any possible injury. To reduce the risk of injury, adult supervision is required.

For your safety, the S Kids will limit the max speed to 4.3 mph (7 km/h) until you complete the New Rider Tutorial. For the first 06 miles (1 km) after completing the New Rider Tutorial, the max speed will be limited to 6.2 mph (10 km/h), after which you can disable the speed limiter via the app and reach a maximum speed of 8.7 mph (14 km/h).

1. Go to a large open area to practice your first ride. Parent(s) must assist the rider during the whole process.

2. Lightly place one foot on the foot mat, while keeping your other foot on the ground holding your weight. Do not press the steering bar with your leg.


Always step on/off from the back of the S Kids

3. Slowly transfer your weight onto the S Kids. The S Kids wil beep, indicating it is now in Balance Mode Slowly step on with your other foot

4. Stand with your weight evenly distributed on both feet and relax, looking straight ahead

5. Gently lean your body forward and backward to control your movement

6. To turn, gently lean left or right against the steering bar.


Features

Bluetooth Remote Control

You can use the Segway-Ninebot app to control your S Kids.

Steps:

1. Open the app and connect your S Kids
2. Tap the icon ( ).

3. Drag the virtual joystick ( ), to control your S Kids


* The default maximum speed is 4.3 mph (7 km/h), but you can change the max speed in the app.

• Do not stand on the S Kids when it is under Bluetooth remote control. Doing so risks serious personal injury or damage
• Do not use Bluetooth remote control in crowded areas or where there is a potential risk of endangering people or property if operated in an unsafe manner.
• The Bluetooth range is 30-50 feet (10-15 meters). If your device goes outside Bluetooth range, the S Kids will stop moving in Bluetooth remote control.

Bluetooth Speaker

You can use your mobile phone to connect the S Kids via Bluetooth.
Let's ride with your phone music!

Steps:

1. Enable Bluetooth on your mobile phone.
2. Search device name: SKidsAUDXXXX.

3. Pair and connect.

Maintenance

Cleaning and Storing

Use a soft, wet cloth to wipe the mainframe clean Hard to remove dirt can be scrubbed with a toothbrush and toothpaste, then cleaned with a soft, wet cloth.

Do not wash your S Kids with alcohol, gasoline, acetone, or other corrosive/volatile solvents. These substances may damage the appearance and internal structure of your S Kids. Do not wash your S Kids with a power washer or high pressure hose.

Make sure the S Kids is powered OFF, the charging cable is unplugged, and the rubber cap on the charging port is tightly sealed before cleaning; otherwise you may expose yourself to electric shock or damage the electronic components.

Store your S Kids in a cool, dry place. Do not store it outdoors for extended periods of time. Exposure to sunlight and temperature extremes (both hot and cold) will accelerate the aging process of the plastic components and may reduce battery life. Prolonged exposure to UV rays, rain and the elements may damage the enclosure materials, store indoors when not in use.

Battery Pack Maintenance

1. Do not use battery packs of other models or brands, otherwise there may be safety risks
2. Only use a Ninebot or Segway approved charge cable. Please use it properly within the rated range
3. Do not place the battery pack in the fire. Doing so will cause battery failure, overheating or even fire and explosion
4. Do not store or charge the battery at temperatures outside the stated limits (see Specifications)
5. Do not discard or destroy the battery. Refer to your local laws and regulations regarding battery recycling and/or disposal
6. Remember to charge the battery after each use. Completely draining the battery may cause permanent damage to the battery

NOTE
Typically, a fully charged battery should retain charge for 120-180 days when on standby. Electronics inside the battery record the charge-discharge condition of the battery; damage caused by over-discharge or under-discharge wil not be covered by the Limited Warranty

A well-maintained battery can perform well even after many miles of riding. Charge the battery after each ride and avoid draining the battery completely. When used at room temperature (70°F [22°C]) the battery range and performance is at its best; whereas using it at temperatures below 32°F (0°C) can decrease range and performance Typically, at 4°F (20°C) range can be half that of the same battery at 70°F (22°C). The battery range will recover when the temperature rises More details are available in the app

Do not attempt to disassemble the battery. Risk of fire. No user-serviceable parts.
Do not ride when the ambient temperature is outside the machine operation temperature (see Specifications) because low/ high temperatures will limit the maximum power/torque. Doing so could cause personal injury or property damage due to slips or falls.
Do not touch the metal contacts, dismantle or puncture the casing. Keep away from metal objects to prevent a short circuit.

Specifications

	Item	Parameters
Product	Name	Ninebot S Kids
	Model	Kids A75C
	Dimensions (Length x Width x Height)	20.8 x 10.2 x 20.8 inch (530 x 260 x 530 mm)
	Net Weight	22.7 lbs (10.3 kg)
Rider	Recommended Age	8+ yrs.
	Required Height	3'6"-5'9" (110-180 cm)
	Payload	44-132 lbs (20-60 kg)
Machine Parameters	Max Speed	8.7 mph (14 km/h)
	Typical Range [II	8 miles (13 km)
	Max. Slope	Approx. 150
	Traversable Terrain	Pavement, packed dirt, slopes < 15°, obstacles < 0.2 in (5 mm), gaps < 0.6 in (15 mm)
	Operating Temperature	14-104°F (-10-40°C)
	Storage Temperature	-4-122°F(-20-50°C)
	IP Rating	IP54
	Charge Time	Approx. 4 hours
Battery	Nominal Voltage	37 V
	Max Charging Voltage	42 V
	Nominal Energy	72 Wh
	Battery Management System	Over-voltage, under-voltage, short circuit, and over-heating protection. Auto sleep and auto wake
	Charging Temperature	32-104°F (0-40°C)
Motors	Nominal Power	280 W x 2
Charger	Input Voltage	100-240 V
	Output Voltage	42 V
	Output Power	25.2W
	Output Current	0.6 A
Tire	Tire	8.5 inch, PU solid tire

[1] Typical Range: tested while riding under full power, 110 lbs (50 kg) load, 77°F(25°C), 60% of max speed on average on pavement.
* Some of the factors that affect range include speed, number of starts and stops, ambient temperature, etc.

Riding Safety

1. S Kids is a recreational product. Before mastering riding skills, you need to practice Neither Ninebot (means Ninebot (Beijing) Tech Co., Ltd. and its subsidiaries and affiliates) nor Segway Inc. is responsible for any injuries or damage caused by a rider's inexperience or failure to follow the instructions in this document.
2. Please understand that you can reduce the risk by following al the instructions and warnings in this manual, but you cannot eliminate all the risks. Remember that whenever you ride the S Kids, you risk injury or death from loss of control collisions, and falls. When entering into public spaces always comply with the local laws and regulations. As with other vehicles, faster speeds require longer braking distances. Sudden braking could lead to wheel slip, loss of balance, or falls. Be cautious and always keep a safe distance between you and other people or vehicles when riding. Be alert and slow down when entering unfamiliar areas.
3. Always wear a helmet when riding. Use an approved bicycle or skateboard helmet that fits properly with the chin strap in place, and provides protection for the back of your head
4. Do not attempt your first ride in any area where you might encounter children, pedestrians, pets, vehicles, bicycles, or other obstacles and potential hazards
5. Respect pedestrians by always yielding the right of way. Pass on the left whenever possible. When approaching a pedestrian from the front, stay to the right and slow down Avoid startling pedestrians. When approaching from behind, announce yourself and slow down to walking speed when passing Please obey local traffic laws and regulations if the situation is different.
6. In places without laws and regulations governing self balancing electric vehicles, comp y with the safety guidelines outlined in this manual. Neither Ninebot nor Segway Inc. is responsible for any property damage, personal injury/death, accidents, or legal disputes caused by violations of the safety instructions
7. Do not allow anyone to ride your S Kids on his/her own unless they have carefully read this manual, watched the safety video, and followed the New Rider Tutorial on the Segway-Ninebot app. The safety of new riders is your responsibility. Assist new riders until they are comfortable with the basic operation of the S Kids Make sure each new rider wears a helmet and other protective gear.
8. Before each ride check for loose fasteners, damaged components, and low tire pressure. If the S Kids makes abnorma sounds or signals an alarm, immediate y stop riding. Diagnose your S Kids via the Segway Ninebot app and cal your dealer/ distributor for service.
9. Be alert! Scan both far ahead and in front of your S Kids — your eyes are your best tool for safely avoiding obstacles and ow traction surfaces (including, but not limited to, wet ground, loose sand, loose gravel, and ice).
10. .To reduce the risk ofinjury, you must read and follow all "CAUTION" and " WARNING" notices in this document. Do not ride at an unsafe speed Under no circumstance shou d you ride on roads with motor vehicles. The manufacturer recommends riders be 8+ years old. Always follow these safety instructions.
    1. People who should not ride the S Kids include:
       1. Anyone under the influence of alcohol or drugs
       2. Anyone who suffers from a disease that puts them at risk if they engage in strenuous physical activity
       3. Anyone who has problems with balance or with motor skills that would interfere with their ability to maintain balance
       4. Anyone whose height or weight is outside the stated limits (see Specifications)
    2. Only ride under adult supervision
    3. Comply with local laws and regulations when riding this product. Do not ride where prohibited by local laws
    4. To ride safely, you must be able to clearly see what is in front of you and you must be clearly visible to others
    5. Do not ride in the snow, in the rain, or on roads which are wet, muddy, icy, or that are slippery for any reason. Do not ride over obstacles (sand, loose gravel, or sticks). Doing so could result in a loss of balance or traction and could cause a fall.
    6. Do not accelerate or decelerate suddenly. Do not accelerate when the S Kids tilts back or sounds an alarm. Do not attempt to override the speed limiter.
11. Do not attempt to charge your S Kids if it, the charger, or the power outlet is wet.
12. As with any electronic device, use a surge protector when charging to help protect your S Kids from damage due to power surges and voltage spikes. Only use the Segway supplied charger. Do not use a charger from any other product
13. Use only Ninebot or Segway approved parts and accessories. Do not modify your S Kids Modifications to your S Kids could interfere with the operation of the S Kids, could result in serious injury and/or damage, and could void the Limited Warranty
14. Do not sit on the steering bar. Doing so could result in serious injury and/or damage to your S Kids
15. S Kids is not intended for use at elevations greater than 2000 m above sea level.
16. Only use the battery(ies) specified by the manufacturer, and only use the charger(s) specified by the manufacturer

Warnings and Cautions

To reduce the risk of injury, adult supervision is required. You must read and understand the Warnings and Riding Safety instructions in this manual before attempting to ride the S Kids. Failure to follow these warnings could result in death or serious injury due to: loss of balance, traction, and/or control, collisions, and falls.

Do not accelerate when the S Kids tilts back or sounds an alarm. Do not attempt to override the speed limiter.

Riding backward is dangerous. Please slow down or get off immediately, otherwise you may lose control and fall.

Do not accelerate abruptly, otherwise you may lose control and fall.

When the battery level is low, please get off immediately, otherwise you may be injured by automatic vehicle shutdown.

When these happen, there will be a voice prompt. During riding, please follow all the safety tips to ensure your safety. The voice prompt feature can be turned off in the app.

To reduce the risk of injury, adult supervision is required

When traversing small bumps or uneven terrain, maintain a moderate speed of 2-6 mph (3-10 km/h) and keep your knees bent. Do not go too slow or too fast; otherwise you may lose control and fall.

Avoid contacting obstacles with the tire/wheel

Avoid slopes steeper than 15°, otherwise you may lose control and fall due to lack of power.

Do not ride through puddles or other bodies of water

Watch your head when passing through doorways

To reduce the risk of injury, adult supervision is required

Do not ride on public roads, motorways, or highways unless the local laws or regulations have exceptions.

For one rider only. Do not ride double or carry any passengers. Do not carry a child.

Do not ride over holes, curbs, steps, or other obstacles.

Do not use a mobile phone or wear earphones when riding.

Contact

Contact us if you experience issues relating to riding, maintenance and safety, or errors/faults with your S Kids.
Americas:
Segway Inc.
14 Technology Drive, Bedford, NH 03110, USA
Toll Free: 1-866-473-4929
Fax: 1-603-222-60-01
Technical Support Email: technicalsupport@segway.com
Website: www.segway.com

Have your S Kids serial number on hand when contacting Segway.
You can find your serial number on the underside of your S Kids or in the app under More Settings > Basic Information.
