5.4 Parameters list

The function parameters have been divided into groups according to the function. Each function group
contains certain function codes applying 3-level menus. For example, "P00.08" means the eighth function
code in the P00 group function, P29 group is factory reserved, and users are forbidden to access these
parameters.
For the convenience of function codes setting, the function group number corresponds to the first level
menu, the function code corresponds to the second level menu and the function parameter corresponds
to the third level menu.
1. Below is the instruction of the function lists:
The first column "Function code": codes of function parameter group and parameters;
The second column "Name": full name of function parameters;
The third column "Description": detailed illustration of the function parameters;
The fourth column "Setting range": valid setting range of the function parameters, displayed on LCD;
The fifth column "Default": the original factory set value of the function parameter;
The sixth column "Modify": the modifying character of function codes (the parameters can be modified or
not and the modifying conditions), below is the instruction:
"○": means the set value of the parameter can be modified on stop and running state;
"◎": means the set value of the parameter cannot be modified on the running state;
"●": means the value of the parameter is the real detection value which cannot be modified;
(The system has limited the automatic inspection of the modifying character of the parameters to help
users avoid modifying by mistake)
The seventh column "No.": the serial number of the function code in the whole function parameters, or
register address during communication
2. "Parameter radix" is decimal (DEC), if the parameter is expressed by hex, then the parameter is
separated from each other when editing. The setting range of certain bits is 0–F (hex).
3. "The default value" means the function parameter will restore to the default value during default
parameters restoring. But the detected parameter or recorded value won't be restored.
4. For a better parameter protection, the system provides password protection. After setting the user
password (set P07.00 to non zero), the system will enter the password authentification state and display
"0.0.0.0.0." while the users press PRG/ESC to enter the editing state of the function parameters. The
users must input correct password or cannot enter. For the factory setting parameter zone, only factory
can enter. (Remind that the users cannot modify the factory parameters by themselves, otherwise, if the
parameter setting is incorrect, damage to the system may occur). If the password protection is unlocked,
the user can modify the password freely and the system will work as the last setting one. When P07.00 is
0, the user password can be cancelled; when P07.00 is non-zero at power on, the parameters can be
protected by the password.
5. When using serial communication to modify the function parameters, the functions of the user
password follow the above rules.
