Goodrive3000 series medium voltage VFD
Set value Function
Shift motor 1 to
35
motor 2
Shift the command to
36
the keypad
Shift the command to
37
the terminals
Shift the command to
38
the communication
Pre-exciting
39
command
Consumption power
40
clear
Consumption power
41
holding
42 External fault input 2 The VFD will alarm and stop after receiving the external fault signal.
43–63 Reserved
Function
Name
code
Polarity of input
P05.10
terminals
The function code is used to set the polarity of the input terminals.
Set the bit to 0, the input terminal is anode.
Set the bit to 1, the input terminal is cathode.
BIT7 BIT6
S8 S7
by P01.12 (DC braking time at stopping).
When the terminal is valid, motor 1 will shift into motor 2. When the
terminal is invalid, the running command returns to the original
state.
When the terminal is valid, the running command will compel to shift
to keypad running command. When the terminal is invalid, the
running command returns to the original state.
When the terminal is valid, the running command will compel to shift
to terminal running command. When the terminal is invalid, the
running command returns to the original state.
When the terminal is valid, the running command will compel to shift
to communication running command. When the terminal is invalid,
the running command returns to the original state.
Start pre-exciting command of the motor until the terminal becomes
invalid.
When the command is valid, the power of the VFD will be cleared.
When the command is valid, the current running of the VFD will not
influence the power.
Description
0x000–0x1FF
BIT5 BIT4
S6 S5
-110-
Instruction
Setting range
0x000–0x1FF
BIT3 BIT2
S4 S3
Goodrive3000 inverter
Default
0x000
BIT1 BIT0
S2 S1
