Function
Name
code
P15.13 Sent PZD2
P15.14 Sent PZD3
P15.15 Sent PZD4
P15.16 Sent PZD5
P15.17 Sent PZD6
P15.18 Sent PZD7
P15.19 Sent PZD8
P15.20 Sent PZD9
P15.21 Sent PZD10
P15.22 Sent PZD11
P15.23 Sent PZD12
Temporary variable 1 for
P15.24
PZD sending
DP communication
P15.25
timeout fault duration
CAN communication
P15.26
timeout fault duration
CANopen
P15.27
communication baud rate
Description
0: Invalid
1: Running frequency (*100, Hz)
2: Set frequency (*100, Hz)
3: Bus voltage (*10, V)
4: Output voltage (*1, V)
5: Output current (*10, A)
6: Output torque actual value (*10, %)
7: Output power actual value (*10, %)
8: Rotating speed during running (*1,
RPM)
9: Running linear speed (*1, m/s)
10: Ramp reference frequency
11: Fault code
12: AI1 value (*100, V)
13: AI2 value (*100, V)
14: AI3 value (*100, V)
15: PULSE frequency (*100, kHz)
16: Terminal input state
17: Terminal output state
18: PID reference (*100, %)
19: PID feedback (*100, %)
20: Motor rated torque
0–65535
0.1–60.0s
0.0: Invalid
0.1–60.0s
0.0: Invalid
0: 1000k
1: 800k
2: 500k
3: 250k
-292-
PROFIBUS communication
Setting range Default
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–20 0
0–65535 0
0.0–60.0 0.0s
0.0–60.0 0.0s
0–7 0
