Goodrive3000 series medium voltage VFD
P05 group––Input terminals
Function
Name
code
P05.00 HDI input type
Set the HDI input type.
Function
Name
code
S1 terminal function 0: No function
P05.01
P05.02 S2 terminal function
P05.03 S3 terminal function
P05.04 S4 terminal function
P05.05 S5 terminal function
P05.06 S6 terminal function
P05.07 S7 terminal function
P05.08 S8 terminal function
Description
0: HDI is pulse input.
1: HDI is switch input.
Description
1: Forward rotation operation
2: Reverse rotation operation
3: 3-wire control operation
4: Forward rotation jogging
5: Reverse rotation jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting
(DOWN)
12: Cancel the frequency change
setting
13: Shift between A setting and B
setting
14: Shift between combination setting
and A setting
15: Shift between combination setting
and B setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Multi- step speed pause
21: ACC/DEC time option 1
22: ACC/DEC time option 2
-106-
Goodrive3000 inverter
Setting range Default
0–1 0
Setting range Default
0–63 0
0–63 0
0–63 0
0–63 0
0–63 0
0–63 0
0–63 0
0–63 0
