Goodrive3000 series medium voltage VFD
The below table is the options of function parameters which permit selecting the same output terminal
function.
Set value Function
0 Invalid
1 In operation
Forward rotation
2
operation
Reverse rotation
3
operation
4 Jogging operation
5 VFD fault
Frequency degree test
6
FDT1
Frequency degree test
7
FDT2
8 Frequency arrival
9 Zero speed running
Upper limit frequency
10
arrival
Lower limit frequency
11
arrival
12 Ready for operation
13 Pre-excitation
14 Overload pre-alarm
15 Underload pre-alarm
Completion of simple
16
PLC step
17
Completion of simple
There are no functions of output terminals.
When the VFD runs, the frequency output is valid.
When the VFD runs forward, the frequency output is valid.
When the VFD runs reversely, the frequency output is valid.
When the VFD jogs, the output is valid.
When there is an VFD fault, the frequency output is valid.
Refer to Function code P08.32 and P08.33 for detailed
information.
Refer to Function code P08.34 and P08.35 for detailed
information.
Refer to Function code P08.36 for detailed information.
The output is valid when both the output frequency and
frequency reference of the VFD are equal to zero.
The output is valid when the running frequency reaches the
upper limit.
The output is valid when the running frequency reaches the lower
limit.
The output is valid when the power of the primary loop and
control loop is set up, and the VFD is ready for operation without
carrying out protection functions.
The output is valid at pre-excitation.
The output is valid after the VFD exceeds the pre-alarm time on
basis of the overload pre-alarm point. Refer to the function codes
P11.08–P11.10 for specific information.
The output is valid after the VFD exceeds the pre-alarm time on
basis of the underload pre-alarm point. Refer to the function
codes P11.11–P11.12 for specific information.
The output is valid after the simple PLC current step is
completed.
The output is valid after one simple PLC cycle is completed.
