INVT Goodrive3000 Series Operation Manual page 264

Goodrive3000 series medium voltage VFD
Function Address
instruction definition
Fault code of the
VFD
Identifying code of
the VFD
Pre-alarm sign
Operation
frequency
Setting frequency
Bus voltage
Output voltage
Output current
Rotation speed
Data meaning instruction
Bit1–2: =00:motor 1
=10:motor 3
Bit3: =0:asynchronous motor
=1:synchronous motor
Bit4: =0:pre-alarm without overload
=1:overload pre-alarm
Bit5: =0: motor without pre-excitation
=1: motor in pre-excitation
Bit0: =0: ready for operation
=1: not ready for operation
Bit1–2: =00:motor 1
=10:motor 3
Bit3: =0:asynchronous motor
=1:synchronous motor
Bit4: =0:pre-alarm without overload
=1:overload pre-alarm
Bit5: =0: motor without excitation
=1: motor in excitation
2102H See the fault type instruction
2103H GD3000-----0x0110
Bit 0: motor overheat pre-alarm (A-OT)
2014H Bit 1: overload pre-alarm (A-OL)
Bit 2–Bit7: reserved
3000H 0–Fmax(unit: 0.01Hz)
3001H 0–Fmax(unit: 0.01Hz)
3002H 0.0–2000.0V(unit: 0.1V)
3003H 0–1200V(unit: 1V)
3004H 0.0–3000.0A(unit: 0.1A)
3005H 0–65535(unit: 1RPM)
=01:motor 2
=11:motor 4
=01:motor 2
=11:motor 4
-259-
MODBUS protocol
R/W
characteristics
R
R
R
R
R
R
R
R
