Goodrive3000 series medium voltage VFD
Function
Name
code
Lower limit of AO1
P06.21
output
Corresponding AO1
P06.22
output to lower limit
Upper limit of AO1
P06.23
output
Corresponding AO1
P06.24
output to upper limit
AO1 output filter
P06.25
time
Lower limit of AO2
P06.26
output
Corresponding AO2
P06.27
output to lower limit
Upper limit of AO2
P06.28
output
Corresponding AO2
P06.29
output to upper limit
AO2 output filter
P06.30
time
Lower limit of AO3
P06.31
output
Corresponding AO3
P06.32 output frequency to
lower limit
Upper limit of AO3
P06.33
output
Corresponding AO3
P06.34 output frequency to
upper limit
AO3 output filter
P06.35
time
Lower limit of HDO
P06.36
output
Description
-100.0%–P06.23
-10.00V–10.00V
P06.21–100.0%
-10.00V–10.00V
0.000s–10.000s
-100.0%–P06.28
-10.00V–10.00V
P06.26–100.0%
-10.00V–10.00V
0.000s–10.000s
-100.0%–P06.33
-10.00V–10.00V
P06.31–100.0%
-10.00V–10.00V
0.000s–10.000s
-100.0%–P06.38
-124-
Goodrive3000 inverter
Setting range Default
-100.0–P06.23 0.0%
-10.00–10.00 0.00V
P06.21–100.0 100.0%
-10.00–10.00 10.00V
0.000–10.000 0.000s
-100.0–P06.28 0.0%
-10.00–10.00 0.00V
P06.26–100.0 100.0%
-10.00–10.00 10.00V
0.000–10.000 0.000s
-100.0–P06.33 0.0%
-10.00–10.00 0.00V
P06.31–100.0 100.0%
-10.00–10.00 10.00V
0.000–10.000 0.000s
-100.0%–P06.38 0.00%
