Goodrive3000 series medium voltage VFD

5.2 Detailed function codes

P00 group––Basic function
Function
Name
code
Run command
P00.01
channel
Select the run command channel of PWM rectifier.
The control command of PWM rectifier includes: start-up, stop and fault reset.
0: Keypad running command channel ("LOCAL/REMOT" light off)
Carry out the command control by RUN, STOP/RST on the keypad.
1: Terminal running command channel ("LOCAL/REMOT" flickering)
Carry out the running command control by the multi-function terminals
2: Communication running command channel ("LOCAL/REMOT" on);
The running command is controlled by the upper computer via communication.
Function
Name
code
Communication
P00.02
running commands
Select the controlling communication command channel of PWM rectifier.
Note: 1, 2 and 3 are extension functions which need corresponding extension cards.
Function
Name
code
P00.03 Running mode
Select the running mode of PWM rectifier.
0: COSφ mode; the reactive current is determined by the power factor.
Note: The mode 0 has voltage loop and needs to set the parameters in P03 group.
Description
0: Keypad command channel (LED
off)
1: Terminal command channel (LED
flickering)
2: Communication command
channel (LED on)
Description
0: 485 communication channel
1: PROFIBUS communication
channel
2: Ethernet communication channel
3: CANopen communication channel
4: Reserved
5: Reserved
6: Reserved
Description
0: COSφ mode
1: Reserved
2: Reserved
-24-
Goodrive3000 PWM rectifier
Setting range
0–2
Setting range
0–6
Setting range
0–2
Default
0
Default
0
Default
0
