INVT Goodrive3000 Series Operation Manual page 49

Goodrive3000 series medium voltage VFD
Function
Name
code
Refer to the fault information.
Function
Name
code
Input terminal state
P10.06
at present fault
Record the input terminal state when fault occurs.
Function
Name
code
Output terminal state
P10.07
at present fault
Record the output terminal state when fault occurs.
Function
Name
code
DC bus voltage at
P10.08
present fault
Record the DC bus voltage when fault occurs.
Function
Name
code
Grid voltage at
P10.09
present fault
Record the grid voltage when fault occurs.
Function
Name
code
Input current at
P10.10
present fault
Record the input current when fault occurs.
Description
32: Out3
Pre-warning type:
05: A-vH1
Description
0x0–0xF
Description
0x0–0xF
Description
0.0–6000.0V
Description
0.0–4000.0V
Description
0.0–6000.0A
-44-
Goodrive3000 PWM rectifier
Setting range
Setting range
0x0–0xF
Setting range
0x0–0xF
Setting range
0.0–6000.0V
Setting range
0.0–4000.0V
Setting range
0.0–6000.0A
Default
Default
0x0
Default
0x0
Default
0.0V
Default
0.0V
Default
0.0A
