Goodrive3000 series medium voltage VFD
Function
Name
code
Select the functions of QUICK/JOG.
0: No function
1: Jogging running: Press QUICK/JOG to begin the jogging running.
2: Shift the display state by the shifting key: Press QUICK/JOG to shift the displayed function code from
right to left.
3: Shift between forward rotation and reverse rotation: Press QUICK/JOG to shift the direction of the
frequency commands. This function is only valid in the keypad command channels.
4: Clear UP/DOWN setting: Press QUICK/JOG to clear the set values of UP/DOWN.
5: Coast to stop: Press QUICK/JOG to coast to stop.
6: Shift the running command sources in sequence: Press QUICK/JOG to shift the running command
sources in sequence.
7: Quick commission mode (According to the non-factory parameter commissioning)
Note: When QUICK/JOG is used to shift between forward rotation and reverse rotation, the VFD does
not record the state after shifting during power off. The VFD will run according to the running direction set
by P00.13 during next power on.
Function
Name
code
QUICK shifting
P07.03 sequence of running
command channel
When P07.02=6, set the shifting sequence of running command channel.
Description
reverse rotation
4: Clear UP/DOWN setting
5: Coast to stop
6: Shift the running command
sources in sequence
7: Quick commission mode
(according to the non-factory
parameter commissioning)
Description
0: Keypad control→terminal control
→communication control
1: Keypad control←→terminal
control
2: Keypad control←→communication
control
3: Terminal control←→
communication control
-127-
Goodrive3000 inverter
Setting range Default
Setting range Default
0–3 0
