INVT Goodrive3000 Series Operation Manual page 69

Goodrive3000 series medium voltage VFD
Function
Name
code
AI3 upper limit
P05.43 corresponding
setting
AI3 input filtering
P05.44
time
P06 group––Output terminals
Polarity selection of
P06.00 digital output
terminal
Relay RO1 output
P06.01
selection
Relay RO2 output
P06.02
selection
P06.03 Reserved
P06.04 Reserved
Delay time of RO1
P06.05
switching-on
Delay time of RO1
P06.06
switching-off
Delay time of RO2
P06.07
switching-on
Delay time of RO2
P06.08
switching-off
P06.09 Reserved
P06.10 Reserved
P06.11 Reserved
P06.12 Reserved
AO1 output
P06.13
selection
P06.14
AO2 output
Description
-100.0%–100.0%
0.000s–10.000s
0x0–0xF
0 stands for positive polarity
BIT0: RO1
BIT1: RO2
BIT2–BIT7: Reserved
0: No output
1: Ready to run
2: In running
3: Fault output
4–31: Reserved
0.000–60.000s
0.000–60.000s
0.000–60.000s
0.000–60.000s
0.000–60.000s
0.000–60.000s
0.000–60.000s
0.000–60.000s
0: Null
1: The set value of the DC
voltage (AC1140V, 100%
-64-
Goodrive3000 PWM rectifier
Setting
Default
range
-100.0–100.0 100.0%
0.000–10.000 0.100s
0x0–0xF 0x0
1
2
0–31
0
0
0.000–60.000 0.000s
0.000–60.000 0.000s
0.000–60.000 0.000s
0.000–60.000 0.000s
0.000–60.000
0.000–60.000
0.000–60.000
0.000–60.000
1
0–20
2
Modify
○
○
○
○
○
●
●
○
○
○
○
●
●
●
●
○
○
